How to verify if NTP sync is working on Linux?

NTP stand for Network Time Protocol, which synchronizes the clock between computer systems over the network.

NTP server keep all the servers in-sync with accurate time to perform time based jobs in an organization. NTP client will synchronize its clock to the network time server.

We already wrote an article about NTP Server, Client installation and configuration. If you would like to check these articles, navigate to the following links:

I’m assuming that we have setup the NTP server and NTP client by referring to the above links. In this guide, we will show you how to verify whether the NTP setup is working or not?

NTP sync status can be verified using the following three commands:

  • ntpq: ntpq is standard NTP query program.
  • ntpstat: It shows network time synchronization status.
  • timedatectl: It controls the system time and date in systemd system.

Let’s understand each of the commands in detail.

Method-1: Checking the status of NTP using ntpq command

The ‘ntpq’ command is used to monitor NTP daemon and determine the performance, which can be identified by querying the NTP servers running on the host.

It runs either in interactive mode or by using command-line arguments. It prints a list of connected peers by sending multiple queries to the server.

If NTP is working properly, you should get the below output:

# ntpq -p

     remote           refid      st t when poll reach   delay   offset  jitter
==============================================================================
*CentOS7.2daygee 133.243.238.163  2 u   14   64   37    0.686    0.151  16.432

Details:

  • -p: Print a list of the peers known to the server as well as a summary of their state.
  • remote: Remote NTP server
  • st: The stratum of the remote peer
  • t: Type of the peer (local, unicast, multicast or broadcast)
  • when: Time the last packet was received, the polling interval (seconds)
  • poll: How frequently to query server (in seconds)
  • reach: Octal bitmask of success or failure of last 8 queries.
  • delay: Network round trip time (in milliseconds)
  • offset: Difference between local clock and remote clock (in milliseconds)
  • jitter: Difference of successive time values from server

Method-2: How to check NTP status using ntpstat command

ntpstat will report the synchronization state of the NTP daemon (ntpd) running on the local machine.

If the local system is found to be synchronized to a reference time source, ntpstat will report the approximate time accuracy.

The ntpstat command returns three types of status codes based on the NTP sync as mentioned below:

  • 0: It returns 0, if clock is synchronised.
  • 1: It returns 1, if clock is not synchronised.
  • 2: It returns 2, if clock state is indeterminant, for example if ntpd is not contactable.
# ntpstat

synchronised to NTP server (192.168.1.8) at stratum 3
   time correct to within 508 ms
   polling server every 64 s

Method-3: Checking NTP sync status with timedatectl command

timedatectl command is used to query and change the system clock and its settings in systemd system:

# timedatectl
or
# timedatectl status

      Local time: Thu 2019-05-30 05:01:05 CDT
  Universal time: Thu 2019-05-30 10:01:05 UTC
        RTC time: Thu 2019-05-30 10:01:05
       Time zone: America/Chicago (CDT, -0500)
     NTP enabled: yes
NTP synchronized: yes
 RTC in local TZ: no
      DST active: yes
 Last DST change: DST began at
                  Sun 2019-03-10 01:59:59 CST
                  Sun 2019-03-10 03:00:00 CDT
 Next DST change: DST ends (the clock jumps one hour backwards) at
                  Sun 2019-11-03 01:59:59 CDT
                  Sun 2019-11-03 01:00:00 CST

Bonus Tips:

Chrony is replacement of NTP client. It can synchronize the system clock faster with better time accuracy and it can be very much useful for the systems which are not online all the time.

Chronyd is smaller in size, it uses less system memory and it wakes up the CPU only when necessary, which is better for power saving.

It can perform well, even when the network is congested for longer periods of time. You can use any of the below commands to check Chrony status:

# chronyc tracking

Reference ID    : C0A80105 (CentOS7.2daygeek.com)
Stratum         : 3
Ref time (UTC)  : Thu Mar 28 05:57:27 2019
System time     : 0.000002545 seconds slow of NTP time
Last offset     : +0.001194361 seconds
RMS offset      : 0.001194361 seconds
Frequency       : 1.650 ppm fast
Residual freq   : +184.101 ppm
Skew            : 2.962 ppm
Root delay      : 0.107966967 seconds
Root dispersion : 1.060455322 seconds
Update interval : 2.0 seconds
Leap status     : Normal

Run the sources command to display information about the current time sources:

# chronyc sources

210 Number of sources = 1
MS Name/IP address         Stratum Poll Reach LastRx Last sample
===============================================================================
^* CentOS7.2daygeek.com          2   6    17    62    +36us[+1230us] +/- 1111ms

Conclusion

In this guide, you learned how to check NTP synchronize status on linux using three different commands.

If you have any questions, feel free to leave a comment. We will get back to you as soon as possible.
